| Technical Data | CUT-40 |
| Rated Input Voltage | 220~240±15% |
| Phase/Frequency | 1Ph/50~60Hz |
| Rated Input Power | 6KVA |
| Rated Duty Cycle | 45% |
| Output Amperage Range | 20~40A |
| Output Voltage | 230V |
| Arc-Starting Mode | Non Touch |
| Cutting Torch Air Pressure | 0.4MPa |
| Max. Cutting Thickness | 12mm |
| Efficiency | 85% |
| Power Factor | 0.76 |
| Protection Grade | IP 23 |
| Insulation Class | F |
| Net Weight | 8.5KG |
| Dimensions | 35*15*23CM |
